Common detection methods of part features

The common detection methods of part features are as follows:

1. Hole position check (checking pin, marking line visual check, marking line pin, etc.)







2. Pin position check (inner hole checking pin, right angle checking block, cross slider+dial gauge, visual check, etc.)




3. Contour/profile surface check (Offset surface+sharp feeler gauge or caliper or GONOGO gauge, flush surface,  dial gauge, etc.)




4. KPC point check (dial gauge, etc.)
